Environmental Protection & Control
EPC-2374
Temperature & Humidity Protection/Control
with Advanced Logic Engine & Data Logging
Many industries require reliable and fast protection from environmental threats. The EPC-2374 was designed around a rugged platform to provide powerful control and protection with great flexibility. Engineered for numerous industrial applications, the EPC-2374 will deliver critical protection and accurate control.
Features
  • Ambient Temperature, Humidity & Dewpoint
  • 2 External RTD inputs (8 optional)
  • 3 Contact Outputs
  • Trip Logic Engine (allows for trip setpoints based upon logic combinations)
  • Time/Date Stamped Event Recording
  • Power Fail Contact Output
  • Configurable Output Assertion/De-assertion Delays
  • RS-232 Communications, Settings and Event Reports
  • Diagnostics and Testing of Outputs
  • Peak High/Low Data Recording of Inputs
  • Data Logging Mode of any or all inputs (captured to terminal) with time/date stamp
  • LCD Display for "Show What You Want" Scrolling View-Points
  • 6 Modes of Operation

Modes
The EPC-2374 was designed for flexibility to meet many applications. With six modes of operation, the unit be configured for the application your require.
  • Trip Above (Trip above setpoint)
  • Trip Below (Trip below setpoint)
  • Trip Inside Window (Trip inside a range of setpoints)
  • Trip Outside Window (Trip outside a range of setpoints)
  • Regulate Heat (Regulation mode)
  • Regulate Cool (Regulation mode)



Test drive the user interface with our online demo. Contact Us for connection instructions emailed to you.
Typical Example of the EPC-2374 Logic Engine. Build your own Logic:





Data Sheets and Literature require Adobe Reader. Get Adobe here

The EPC-2374 is Engineered & Made in the USA
